System 30 - Genoa Ball Bearing Car, Single Ball Bearing Sheave

The System 30 Performance Single sheave Genoa Car is designed for high performance jib/genoa trim with 2:1 purchase. The car is anodized aluminium with Torlon Ball Bearings and a ø60 mm V-shaped Acetal sheave in a stainless sheave holder supported by a stainless spring stand up.

For the control line, the car features a ø50 mm machined aluminium sheave with Torlon ball bearings separated from each other in a ball cage. This prevents ball-to-ball contact and makes for low friction.

System: 30p
SubType: ballBearing
Safe working Load: 1500 kg
Breaking Load: 3000 kg
Pinstop: 0
Purchase: 2 (N:1)
Length: 190 mm
Width: 75 mm
Min Rv: 5500 mm
Min Rh: 5500 mm
